| Product Features |
|
|
|
|
|
|
|
| Overload protection | Range | 5% | Type | Constant current auto-recovery |
|
|
| Over voltage protection | 110-150% rated output power |
|
|
| Withstand voltage | I/P-O/P:3KVAC 5S | Working temperature | -30～+60℃ |
|
|
| Protection | Over Current /Short Circuit /Over Voltage protection |
|
|
| Safty standards | EN60950-1,EN60335-1,EN61558-1/-2-16 |
|
|
| Regulatory standards | CE EAC EMC |
|
|
| EMC EMI standards | EN55032(CISPR32),Class B,EN55014,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2) |
|
|
| Output | Rated output can be customized |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| SPECIFICATION |
|
|
|
|
|
|
| OUTPUT 输出 | DC VOLTAGE | 12V/24V | 12V/24V | 12V/24V | 12V/24V | 12V/24V |
|
| 输出电压 |
| CURRENT (max) | 1.67A(12V) | 2.5A(12V) | 3.35A(12V) | 4.17A(12V) | 5A(12V) |
|
| 最大输出电流 | 0.83A(24V) | 1.25A(24V) | 1.67A(24V) | 2.1A(24V) | 2.5A(24V) |
|
| RATE POWER | 20W | 30W | 40W | 50W | 60W |
|
| 额定功率 |
| RIPPLE & NOISE(max） | ≥200MV | ≥200MV | ≥200MV | ≥200MV | ≥200MV |
|
| 纹波与噪声 |
| INPUT 输入 | VOLTAGE RANGE | 180-264V | 180-264V | 180-264V | 180-264V | 180-264V |
|
| 输入电压范围 |
| EFFICIENCY(Typ.) | 85% | 85% | 85% | 86% | 86% |
|
| 电源效率（典型值） |
| INRUSH CURRENT(Typ） | COLD START 冷启动 60A/230VAC |
| 浪涌电流 |
| LEAKAGE CURRENT | <2mA 230VAC |
| 漏电流 |
| PROTECTION 保护功能 | OVERLOAD | 110-150% rated output power.额定输出功率的110-150% |
| 过载保护 | Protection type:Hiccup mode recover automatically,打嗝模式,自恢复 |
| OVER VOLTAGE | 13.8-16.2V (12V) / 27.6-32.4V (24V) |
| 过压保护 | Protection type:Shut down o/p voltage，关断输出电压，重启恢复 |
| OVER TEMPRETURE | Protection type:Shut down o/p voltage，关断输出电压，重启恢复 |
| 过温度保护 |
| ENVIRONMENT 环境 | WORKING TEMP | -30～+40℃ |
| 工作温度 |
| WORKING HUMIDITY | 20-80% RH non-condensing 无冷凝 |
| 工作湿度 |
| STORAGE TEMP&HUMIDITY | 10-90% RH non-condensing 无冷凝，-40～+85℃ |
| 储存温度及湿度 |
| VIBRATION | 10-500Hz,2G 10min/1cycle,period for 60min.each along X,Y,Z axes |
| 振动 | 10-500Hz,2G 10分钟/周期 X,Y,Z 轴各60分钟 |
| OVER VOLTAGE CATEGORY | III,Compliance to EN61558,EN50178,EN60664-1,EN62477-1 |
| 过电压等级 |
| SAFETY & EMC 安规及电磁兼容性 | SAFETY STANDARD | Compliance to EN60950-1,EN60335-1,EN61558-1/-2-16 |
| 安规标准 |
| WITHSTAND VOLTAGE | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC |
| 耐压指标 |
| EMC EMISSION | Compliance to B,EN55015,EN61347-2-13 |
| 电磁兼容辐射 |
| EMC IMMUNITY | Compliance to EN61347-1, EN61547 |
| 电磁兼容抗扰度 |
